~30 ton, “Greenerd” C-Frame HYDRAULIC PRESS

$2,500.00 USD

Note: Unit not working at the moment.   SOLD AS IS. This machine will ship to U.S.A. Duty Free.

Description

NOTE: Unit not working at the moment

Specifications:

  • Manufacturer:                  Greenerd  (U.S.A.)
  • Capacity:                          Approx. 30 Tons
  • Stroke:                              18″ +
  • Total Daylight:                 35½” Bottom of crown to top of bolster
  • Bolster:                             2″ thick (removable)
  • Bolster area:                    36″ wide x 15½” F-B
  • Bed area:                          20″ wide x 14″ F-B
  • Slot in bed:                       5″ wide x 10″ deep (also in bolster)
  • Throat:                             9″ (to center of ram)
  • Cyl diameter:                   9″ (exterior) (8″ piston?)
  • Piston rod diameter:        4.5″
  • Work height:                    34″ above floor (bolster installed)
  • Motor:                              20 HP, 230/460 Volt, 60 Cycle, 3Ph
  • Hydraulics:                       Vickers
  • Valving:                            Vickers
  • Height main frame:          97½”
  • Height overall:                  109½” (includes top mounted valving)
  • Front to back:                   66″ (including motor assembly)

INCLUDES:

  • Disconnect switch
  • 20 HP magnetic motorstarter

COMMENTS:
AS IS. This machine will ship to U.S.A. Duty Free.

Price, FOB your carrier, Montreal,Canada
